Applicable scope:
All various kinds of PET detergent bottles、PLASTIC oval-shaped container products.
Features:
1.Wrap-around labeling on special oval cans and bottles.
2.Vacuum label suction of labels to control label feeding and accurate labeling;
labeling accuracy is ±0.5mm.
3.Proper control on glue film thickness to avoid peeling and glue omission
(available in optional water glue and hot melt adhesive).
4.Applicable with labels in lithographic paper, coated paper, lacquered paper or
foil paper.
5.Can be connected with a conveyor belt on the production line.
6.Labeling cost reduction.
7.Universal label holder to accommodate different label sizes and shapes, and five-
minute quick adjustment.
8.Labeling speed: 16-25 bottles/min.
Applicable Products
.gif)
| Machine dimensions | 2000 x 1300 x 170 mm (L x W x H) |
| Machine weight | 600 kg |
| Maximum labeling size | (standard type)180 x 160mm (L x W):(widen type) 280 x 160mm (L x W) |
| Power rating | 3-phase220V 50 / 60 HZ |
| Dry compressed air | 6~8kg/cm2 |
